Smoothie Machine HM160E

Operation: Option 1 By QR Code Scan To Do Any Menu Smoothies Cup

1.Print the QR code and stick outside the cups.
2.Put the frozen fruit & veggies into the 16oz cups and stick the QR code outside the cup.
3.Storage the cups into the refrigerator between-10 to -18ºC. Fruit cube size below2.5*2.5cm.
4.Customers choose their favourite mixer cup（fruit & veggies150G-180G）.
5.Scan the QR code then the machine door will open automatically.
6.Customer put the cups in the holder under the blend blade.
7.Machine start to blend the fruit mixer to be smoothies.
8.The machine door will open again automatically.
9.Smoothie finished , customers can get the smoothie from the machine and enjoy it .
10.The machine door will close and do cleaning automatically.

Smoothie Machine One-Click operation video for operation

Operation: Option 2 by Press “PUSH” button

1.Put the machine in the table top at chain catering ,bakery,fruit shops,snack shops etc.
2.Prepared the frozen /fresh fruit & veggies into the 16oz cups.
3.Storage the cups into the refrigerator between -10 to -18ºC. Fruit cube size below2.5*2.5cm.
4.Customers choose their favourite mixer cup.（fruit & veggies150G- 160G）
5.Shop assistant help to do the process of blending mixer cup.
6.put the cups in the holder under the blend blade,Press button “PUSH”.
7.The machine door will open automatically.
8.Machine start to blend the fruit mixer to be smoothies.
9.Smoothie finished , get the smoothie from the machine and enjoy it.
10.The machine will do cleanning automatically.

Order Process

Step 1:
13.3’‘ HD screen for advertisement and monitoring operation
Step 2:
Colored light strip
Step 3:
Food-grade stainless steel blending work automatically. Filling in 100-300ML water mixed to be smoothie
Step 4:
Transparent acrylic window can check blending process and prevent dust from entering
Step 5:
Flavour options : to add Milk or flavour sauce
Step 6:
Responsive QR Code sensor to setup all the information ( blender time , speed , add water )
Step 7:
Option : you can add credit card to pay it

Automatic High Speed Blender

Automatic blend function:
When the client put the cup into the blender house that will automatic blend frozen fruit.
High speed:
The speed of blender can be reach 1000 turn/min, the mixture will be more smoother.
Customized size cup:
The customized size cups are perfectly fit the holder, the cups will not be broken of high speed blender.

Automatic Clean System

Clean and Hygiene:
1-Self-cleaning：
Machine with auto self-cleaning after making smoothies drinks each time .
2-Regular-time automatic cleaning：
No smoothies drinks-making for half an hour, and the machine cleans them automatically.
Save water:
Less water is required to wash and maintain machine‘s hygiene each cup.

Automatic J UV lamp sterilization

UV lamp sterilization：
Machine open the UV lamp for sterilization on regular time.
UV lights can be very effective at killing viruses, mold, and bacteria. It can ensure hygiene.

Water Input And Output System

Clean and Hygiene:
Self-cleaning:
Machine with auto self-cleaning after each cup.
Save water:
Less water is required to wash and maintain machine’s hygiene.

Each F1avor Has Its Own QR Code

Supply QR code for free!
1.Hommy engineer has design smoothie machine QR system
2.you can base on different smoothie flavour to Generate new QR code
3.you can setup all the information for each flavour smoothie data

QR Code Programmers System

Specification

Model Number	HM-160E
Feature	Tabletop type
Advertisement	13.3” advertising HD screen
Function	QR code scan（one-click operation）/Blending automatically/smoothie serve/blade cleaning automatically
Payment Term	Credit Card option
Fruit cube offering	3-4 flavors of fruits cube size from 1.51.5cm to 2.52.5cm
Production Capacity	40-50 seconds/cup
Matched cup type	16 OZ plastic cup ; cup size :9558127MM
Electricity Consumption	3 to 4 degrees per day
Rated power	500W；2.5A , Speed :MAX 20000RMP
Voltage	220~240V;50/60Hz , 1phase Or 110~120V;60Hz , 1phase
Language	Chinese, English , Spanish , France,German,Korean ETC.
Remote monitoring system	use mobile phone to check machine status, sold out of alert, material shortage of remind
Guarantee Policy	18 months guarantee for whole machine
Net Weight	43 kg
Overall Dimensions(mm)	352478833
